S7 1re série
Sonora-Radio; Paris, Puteaux
- Country
- France
- Manufacturer / Brand
- Sonora-Radio; Paris, Puteaux
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 100817
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 135 kHz
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Details
- Visual Tuning Indicator pre Eye
- Power type and voltage
- AC/DC-set / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Power out
- 0.9 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: S7 [1re série] - Sonora-Radio; Paris, Puteaux
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 340 x 420 x 300 mm / 13.4 x 16.5 x 11.8 inch
- Notes
-
2 gammes d'ondes : PO de 200 à 580 m, GO de 1000 à 1950 m. Dispositif d'accord silencieux, accord visuel. Anti-fading amplifié agissant sur les lampes HF, changeuse de fréquence et MF. Réglage de tonalité. Lampes cadran : 2 x 6 V / 0.1 A.
Ébénisterie noyer verni avec cache du HP et enjoliveur en bakélite.
Pour functionnement sur 130 ou 220 volts un cordon résistant (50 ou 290 ohms) doit être intercalé.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Price in first year of sale
- 1,850.00 FRF
- Circuit diagram reference
- La Documentation du Revendeur - Radio
- Literature/Schematics (1)
- -- Original prospect or advert
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
