• Country
• France

• Manufacturer / Brand
• Miracle, Radio-Lyon, SORAL (S.O.R.A.L.); Paris, Saint-Gildas-des-Bois

• Year
• 1947 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 235702

• • Brand: miracle

• Number of Tubes
• 6

• Valves / Tubes
• ECH3 EF9 EBF2 EL3N EM4 1883

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: T-83 - Miracle, Radio-Lyon, SORAL S.O

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 530 x 305 x 265 mm / 20.9 x 12 x 10.4 inch

• Net weight (2.2 lb = 1 kg)
• 10.5 kg / 23 lb 2 oz (23.128 lb)

• Author
• Model page created by Manfred Rathgeb. See "Data change" for further contributors.

• Other Models

• Here you find 54 models, 48 with images and 13 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
