Radiola 1587 V
SR, Svenska Radioaktiebolaget (SRA, Radiola); Stockholm
- Country
- Sweden
- Manufacturer / Brand
- SR, Svenska Radioaktiebolaget (SRA, Radiola); Stockholm
- Year
- 1958 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 246778
-
- Brand: Radiola
- Number of Tubes
- 9
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 127; 150; 220; 240 Volt
- Loudspeaker
- 5 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiola 1587 V - SR, Svenska Radioaktiebolaget
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 872 x 750 x 382 mm / 34.3 x 29.5 x 15 inch
- Notes
-
FM antenna in cabinet walls.
AM frame antenna in cabinet frame.
Record changer: Garrard RC 120 SVH MKII.
- Net weight (2.2 lb = 1 kg)
- 37 kg / 81 lb 8 oz (81.498 lb)
- Author
- Model page created by Ola Gröndalen. See "Data change" for further contributors.
