Radioear Crystal Receiver Large box with buzzer early

Standard Radio & Electric Co. (Giblin); Pawtucket, Rhode Island

Data
Forum
Pictures
Collections

  • Year
  • 1921
  • Category
  • Detector-Radio (Crystal or diode, without tubes/transistors)
  • Radiomuseum.org ID
  • 234906

 Technical Specifications

  • Main principle
  • Crystal or Solid State Detector
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radioear Crystal Receiver [Large box with buzzer early] - Standard Radio & Electric Co.
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 10.75 x 5.5 x 7.75 inch / 273 x 140 x 197 mm
  • Notes

  • The Standard Radio & Electric Company Giblin Radioear Crystal Receiver was available in at least three different versions of this set and possibly four. (Sievers mentions in Crystal Clear a model in the smaller box without the test buzzer.) The first version came in a smaller box than the later two versions. In this version the wooden case is large enough to house the headphones and spare honeycomb coils. The binding post legends are no longer stamped into the wood next to the post. The chassis was identical to the earlier small box set.

    A Giblin-Remler Type 35 Honeycomb coil was supplied with the set for the reception of amateur signals. Other coils could be purchased to increase the wavelength range. For commercial and radio-phone signals in the 300 to 1,200 meter range a Type 100 Honeycomb coil was required. To receive time signals from Arlington on 2,500 meters a Type 300 coil was needed.

  • Author
  • Model page created by Alan Larsen. See "Data change" for further contributors.
