Concerton V20
Stern & Stern (Concerton / Conserton), S&S; Stockholm
- Country
- Sweden
- Manufacturer / Brand
- Stern & Stern (Concerton / Conserton), S&S; Stockholm
- Year
- 1930/1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 115722
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- TRF with regeneration; 1 AF stage(s)
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 220 Volt
- Loudspeaker
- Magnetic loudspeaker (reed) generic. / Ø 25 cm = 9.8 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Concerton V20 - Stern & Stern Concerton /
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 378 x 294 x 200 mm / 14.9 x 11.6 x 7.9 inch
- Author
- Model page created by Hans-Dieter Haase † 5.2.18. See "Data change" for further contributors.
