Memocord 304B

• Country
• Austria

• Manufacturer / Brand
• Stuzzi Ges. mbH; Wien

• Year
• 1963/1964

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 73727

• • alternative name: RKF

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 3

• Semiconductors
• OC75 OC75 OC72

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Dry Batteries / C: 1 x 1.5 & PP3: 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.02 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Memocord 304B - Stuzzi Ges. mbH; Wien

• Dimensions (WHD)
• 116 x 80 x 36 mm / 4.6 x 3.1 x 1.4 inch

• Notes

• Bandgeschwindigkeit 3,3cm/s. Spieldauer 60 Minuten, 4-Spur-Technik zu je 15 min.
  Mikrofon-Lautsprecher 24 Ω eingebaut.

  Zubehör (Auszug):

  • Spezial-Tonband MT430
  • Fußschalter MF426
  • Kugelschreiber-Mikrofon (Secret Pen Mike)
  • Telefon-Adapter (Suction Cup Telephone Mike)

  Importeur für die USA Lincoln Electronics. Preis in USA 139.50 $.

• Net weight (2.2 lb = 1 kg)
• 0.3 kg / 0 lb 10.6 oz (0.661 lb)

• Price in first year of sale
• 1,380.00 öS

• Source of data
• -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
