Powerstat Variable Autotransformer 10B
Superior Electric Co, The; Bristol, CT
- Country
- United States of America (USA)
- Manufacturer / Brand
- Superior Electric Co, The; Bristol, CT
- Year
- 1955 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 332197
Powerstat 10B bottom view
Powerstat 10B top view
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 120 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Various materials
- from Radiomuseum.org
- Model: Powerstat Variable Autotransformer 10B - Superior Electric Co, The;
- Shape
- Chassis only or for «building in»
- Notes
-
The Superior Electric Powerstat 10B is a panel-mounted variable autotransformer with an input of 120VAC and variable output of 0-120 (if operated at 50 Hz) and 0-120 or 0-132 if operated at 60 Hz. Current rating is 2.25 A. Like similar devices often called Variacs, the VT-2 has a toroid core and a single winding. These exposed units would normally be built into other equipment such as power supplies.
- Mentioned in
- the specifications on the device itself
- Author
- Model page created by Rich Post. See "Data change" for further contributors.
