Symphonie
Superla, J.A. Pieuchot; Paris
- Country
- France
- Manufacturer / Brand
- Superla, J.A. Pieuchot; Paris
- Year
- 1947 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 114325
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110-245 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Symphonie - Superla, J.A. Pieuchot; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 630 x 340 x 310 mm / 24.8 x 13.4 x 12.2 inch
- Net weight (2.2 lb = 1 kg)
- 13.3 kg / 29 lb 4.7 oz (29.295 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Franz-Josef Haffner. See "Data change" for further contributors.
