Nornan LVB1210
Svenska Cykelfabriken, Varberg
- Country
- Sweden
- Manufacturer / Brand
- Svenska Cykelfabriken, Varberg
- Year
- 1952 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 129307
-
- alternative name: Tobo Bruk, Tobo
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Line / Batteries (any type) / AC 110; 127; 220; 240 / ? Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Nornan LVB1210 - Svenska Cykelfabriken, Varberg
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 380 x 310 x 150 mm / 15 x 12.2 x 5.9 inch
- Price in first year of sale
- 298.00 SEK
- Source of data
- - - Manufacturers Literature
