• Country
• Sweden

• Manufacturer / Brand
• Svenska Cykelfabriken, Varberg

• Year
• 1952 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 129307

• • alternative name: Tobo Bruk, Tobo

• Number of Tubes
• 5

• Valves / Tubes
• DK92 DF91 DAF91 DL94 EZ40

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Line / Batteries (any type) / AC 110; 127; 220; 240 / ? Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Nornan LVB1210 - Svenska Cykelfabriken, Varberg

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 380 x 310 x 150 mm / 15 x 12.2 x 5.9 inch

• Price in first year of sale
• 298.00 SEK

• Source of data
• - - Manufacturers Literature

• Other Models

• Here you find 135 models, 50 with images and 15 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Svenska Cykelfabriken, Varberg
