• Country
• France

• Manufacturer / Brand
• Innovation, Innophone; Paris

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 277424

• Number of Tubes
• 4

• Valves / Tubes
• 1R5 1T5 1S5 3S4

• Main principle
• Superheterodyne (common); ZF/IF 280 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 1,5 & 67,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Technifrance Minature - Innovation, Innophone; Paris

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 240 x 150 x 65 mm / 9.4 x 5.9 x 2.6 inch

• Notes

• Ce modèle est identique au Technifrance Miniature, mais le couvercle est estampé avec "Innovation".

• Author
• Model page created by Justo Puertas-Paule. See "Data change" for further contributors.
