Inconnu - Unknown 2
Telecson; Toulouse
- Country
- France
- Manufacturer / Brand
- Telecson; Toulouse
- Year
- 1951 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 227157
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Inconnu - Unknown 2 - Telecson; Toulouse
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 580 x 355 x 290 mm / 22.8 x 14 x 11.4 inch
- Notes
-
Achtung: Spartrafo!
Ein KW-Bereich gespreizt (BE). Skala: nur drei deutsche Stationen (Hambourg, Baden-Baden und Allemagne allgemein). Der Lautsprecher (mit Gehäuse) wird über Stecker mit dem Chassis verbunden.
- Net weight (2.2 lb = 1 kg)
- 9.5 kg / 20 lb 14.8 oz (20.925 lb)
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
