Telectronic WT (3)
Telectronic; Paris
- Country
- France
- Manufacturer / Brand
- Telectronic; Paris
- Year
- 1957 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 224922
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 115; 145; 220; 240 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 17 cm = 6.7 inch
- Power out
- 1 W (3 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Telectronic WT - Telectronic; Paris
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 410 x 205 x 390 mm / 16.1 x 8.1 x 15.4 inch
- Notes
-
2 pistes, vitesses 9.5 et 19cm/s, diamètre des bobines 18cm,
1 moteur, 1 HP Audax 17 cm T17PRA12 plus 1 tweeter Audax 8 cm TA8.
Cette variante WT (3) du Telectronic W ne comporte plus le tube redresseur EZ80 qui est remplacé par un redresseur sec B250C80.
- Net weight (2.2 lb = 1 kg)
- 13 kg / 28 lb 10.1 oz (28.634 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Raymond Gradelle. See "Data change" for further contributors.
