• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1980/1981

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 90099

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 36

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 180 W (260 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: FM HiFi Stereo/FM-AM Receiver TR550 HiFi Ch= 2000 - Telefunken Deutschland TFK,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 455 x 135 x 360 mm / 17.9 x 5.3 x 14.2 inch

• Notes
• Eingänge: 1 x Phono (MM), 1 x Band, 1 x Reserve, Monitor, 2 Lautsprecherpaare anschließbar / schaltbar. Lautsprecherimpedanz 4-16Ohm, 2 Kopfhörerausgänge, Filter: Low/high/FM-Muting/ASL/AFC/Loudness, 7 Sensoren für Fixprogramm-Speicherung, Tuning-Einstellung und Feldstärkeanzeige über LED-Leuchtband

• Net weight (2.2 lb = 1 kg)
• 11.2 kg / 24 lb 10.7 oz (24.67 lb)

• Price in first year of sale
• 1,100.00 DM

• Literature/Schematics (1)
• -- Schematic (FFH Braune Liste 80/81)

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
