• Country
• France

• Manufacturer / Brand
• Thomson (marque), Thomson-Houston (CFTH); Paris

• Year
• 2000 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 323538

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Other Combination - see Notes; Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 50 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Altima 580 Ch= CRDK2507 - Thomson marque, Thomson-

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 306 x 329 x 380 mm / 12 x 13 x 15 inch

• Notes

• Radio-CD-Cassette combination with 2 auto-reverse tape decks and detachable speakers.
  Frequency response: 40 Hz - 20 kHz (-3 dB) with subwoofer
  Output power: 2 x 25 W (RMS), subwoofer: 2x 60 W (RMS)
  Remote control.

• Net weight (2.2 lb = 1 kg)
• 11 kg / 24 lb 3.7 oz (24.229 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Julián Muñoz Lorenzo. See "Data change" for further contributors.
