- Country
- France
- Manufacturer / Brand
- Thomson (marque), Thomson-Houston (CFTH); Paris
- Year
- 2000 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 252929
Baugruppen
Titelbild Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop; ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Printed Circuit Board
- from Radiomuseum.org
- Model: Ch= ICC20 - Thomson marque, Thomson-
- Shape
- Chassis only or for «building in»
- Notes
-
Stereo Farbfernseh Chassis ICC20.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
