- Country
- France
- Manufacturer / Brand
- Titus Konteschweller, Dr. Titus; Paris
- Year
- 1924
![perfect model](/img/sternRot.gif)
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 114519
- Number of Tubes
- 2
- Valves / Tubes
- Main principle
- Special principle (see notes); Super Regenerativ
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Storage and/or dry batteries / 4 & 80 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case, TUBES VISIBLE.
- from Radiomuseum.org
- Model: Normal - Titus Konteschweller, Dr.
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Notes
-
Montage super-réaction, Modèle normal.
Montage super-réaction modèle normal. See also in: P. HEMARDINQUER «LA SUPERHETERODYNE ET LA SUPERREACTION» [1926] Pages 126-129 and: La Nature 1925 page 248 and 397 or «Radiofil Magazine» N° 66, Page 48, «Titus Konteschweller Le champion de la superréaction».
The model "Ordinaire" in this family of very similar models has two flaps, the "Normal" has one pair of coils and one flap and the "Universel" has two pairs of of coils.Voir un article sur Titus Konteschweller avec le schéma de base de l' appareil.
- Mentioned in
- Le Guide du Collectionneur TSF Biraud/Foster, Vol. II (page 363)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
- Other Models
-
Here you find 10 models, 10 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Titus Konteschweller, Dr. Titus; Paris
Forum contributions about this model: Titus Konteschweller: Normal
Threads: 1 | Posts: 1
I posted photos of my Dr. Titus "Normal" model today and wanted to state that mine differs from the photos I've seen of the few existing examples of this model in that it has an extra dial in the upper right hand of the top panel. It acts as a vernier control for the variable capacitor which is dealt with using a single combination dial on the other examples I've seen.
David Smith, 13.Mar.24
