Turkos 406
Tjerneld Radio AB; Stockholm
- Country
- Sweden
- Manufacturer / Brand
- Tjerneld Radio AB; Stockholm
- Year
- 1958 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 204602
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Turkos 406 - Tjerneld Radio AB; Stockholm
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 530 x 380 x 240 mm / 20.9 x 15 x 9.4 inch
- Notes
- There is one big 4 ohm loudspeaker and two 20 ohm small speakers. The big speaker is 25 x 17,5 cm (elliptical) and the small are 12,5 cm in diameter (round). The selenium rectifier is AEG B250 C 100L. Power consumption is 60 W.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Timo Haveri. See "Data change" for further contributors.
