Ultra Twin 50 R568

Ultra Electric Ltd.; London

Datos
Foro
Imágenes
Colecciones

  • Año
  • 1950
  • Categoría
  • Radio - o Sintonizador pasado WW2
  • Radiomuseum.org ID
  • 101821
    • alternative name: Ultra Radio and Television

Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.

 Especificaciones técnicas

  • Numero de valvulas
  • 4
  • Principio principal
  • Superheterodino en general; ZF/IF 470 kHz; 2 Etapas de AF
  • Número de circuitos sintonía
  • 6 Circuíto(s) AM
  • Gama de ondas
  • OM y OL
  • Tensión de funcionamiento
  • Red / Baterías o pilas / 200-250 / 7.5 & 85.5 Volt
  • Altavoz
  • Altavoz dinámico (de imán permanente) / Ø 5 inch = 12.7 cm
  • Material
  • Inyectado (se desconoce si bakelita o plástico).
  • de Radiomuseum.org
  • Modelo: Ultra Twin 50 R568 - Ultra Electric Ltd.; London
  • Forma
  • Portátil > 20 cm (sin la necesidad de una red)
  • Anotaciones

  • Second model in the "Twin" range.
    A lever on a spring loaded slide switch locks the radio in the "battery" mode when the mains plug is parked in a holder. This was to suit a UK 5A two pin and some smaller 5A 3 pin prior to the 3 rectangular pin system adopted in the late 1950s. The chassis is also connected directly to one wire of the mains cable when in "mains" mode (default) and power switch on. Today the set is best operated via an external isolation transformer or on batteries.
    There is an external aerial socket isolated by a Silver Mica capacitor.

    This Twin 50 uses a combined battery. Presumed to be B127 (size & rating and claimed by Trader 963),  If the radio has two plugs, then it's the Carnival Twin R656 or some other Twin as  R&TS states these  use separate batteries (Presume B129 and AD39 as claimed by trader 963 for Twin 50)



  • Precio durante el primer año
  • 13.00 GBP
  • Procedencia de los datos
  • -- Original-techn. papers.
  • Referencia esquema
  • Radio and TV Servicing books (R&TVS) book
  • Documentación / Esquemas (1)
  • Trader Sheet 963.
  • Autor
  • Modelo creado por Peter Hoddow. Ver en "Modificar Ficha" los participantes posteriores.

 Colecciones | Museos | Literatura

 Forum

Contribuciones en el Foro acerca de este modelo: Ultra Electric Ltd.;: Ultra Twin 50 R568

Hilos: 1 | Mensajes: 2

A puzzling aspect is the battery type. The B129 + AD39 use the 3 pin and larger 2 pin HT & LT connector (same as B126 and AD38) and that is what is on my Twin 50, with dabs of red marker on the solder, as on the internal solder joints of the set, suggesting a factory fitting.

But the B127 "combo" pack uses a 8 way + key socket  with keyed 4  pin + dummy key pin connector of "type W"



B129 + AD30 side by side is about 286 x 57 x 96mm max

B127 280 x 95 x 55 mm approx

The Public may have been suspicious of "balanced" combi packs and preferred the separate HT & LT?

Michael Watterson, 19.Jul.12
