Radio-Phonofil

Unic-Radio - voir aussi Ribet-Desjardins; Montrouge

Data
Forum
Pictures
Collections

  • Year
  • 1951
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 321598

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • Permanent or electro-dynamic (moving coil), system not known yet.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Radio-Phonofil - Unic-Radio - voir aussi Ribet-
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 610 x 1100 x 410 mm / 24 x 43.3 x 16.1 inch
  • Notes

  • 4 gammes d'ondes dont 2 OC couvrant de 13 à 103 m avec vernier spécial. Contre-réaction BF 4 positions.

    Tourne-disques 78 tours à pointe saphir.
    Engeristreur sur fil.

  • Net weight (2.2 lb = 1 kg)
  • 45 kg / 99 lb 1.9 oz (99.119 lb)
  • Mentioned in
  • -- Original prospect or advert (Publicité 1951)
