Inconnu - Unknown 1
Univers, Société Radio-Électrique; Paris
- Country
- France
- Manufacturer / Brand
- Univers, Société Radio-Électrique; Paris
- Year
- 1951 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 296213
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif. Vibreur
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / AC: 110-240 / 2 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Metal case
- from Radiomuseum.org
- Model: Inconnu - Unknown 1 - Univers, Société Radio-
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 330 x 240 x 150 mm / 13 x 9.4 x 5.9 inch
- Notes
-
Redresseurs selenium sur alimentation secteur. Haute Tension générée par un vibreur GALVIN sur alimentation batterie plomb/acide 2V.
Voir aussi modèle similaire Colonial Mixte.
- Author
- Model page created by Philippe Harang. See "Data change" for further contributors.
- Other Models
-
Here you find 2 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Univers, Société Radio-Électrique; Paris
