• Country
• Australia

• Manufacturer / Brand
• Peak (brand), H. Rowe & Co. Pty. Ltd.; Richmond

• Year
• 1969–1972

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 258184

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• 2SB186 2SB186 2SB186 2SB186 2SB405 2SB405 2SB405 2SB405

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 7 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Peak - Solid State - Stereophonic Amplifier STP-708 - Peak brand, H. Rowe & Co. Pty.

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 8.5 x 3 x 5.3125 inch / 216 x 76 x 135 mm

• Notes

• The Peak STP-708 8-Transistor Solid State Stereo Amplifier is designed to operate with crystal phono cartridge only. The use of a magnetic cartridge requires phono-tape preamplifier PRE-302 (or similar).

  Output power: 3.5 W peak power per channel.
  Power requirements: 117 or 230 volts AC, 50 or 60 Hz.

  Australian version appears to have factory/distributor fitted transformer with only 220 and 240 V taps.

  Made in Japan by unknown manufacturer.

• Net weight (2.2 lb = 1 kg)
• 1.5 kg / 3 lb 4.9 oz (3.304 lb)

• Price in first year of sale
• 41.00 AUS $

• Mentioned in
• Mingay's Price Service (Feb 1970 to Aug 1972.)

• Literature/Schematics (1)
• - - Manufacturers Literature (Instruction leaflet that came with the unit)

• Author
• Model page created by Bruce Wilkie. See "Data change" for further contributors.
