All Transistor inconnu - unknown 2
Visseaux / Télévisso; Lyon / Paris
- Country
- France
- Manufacturer / Brand
- Visseaux / Télévisso; Lyon / Paris
- Year
- 1965 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 357748
- Number of Transistors
- 6
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 0.5 W (undistorted)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: All Transistor inconnu - unknown 2 - Visseaux / Télévisso; Lyon /
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 310 x 180 x 80 mm / 12.2 x 7.1 x 3.1 inch
- Notes
-
Gerät mit Ferritantenne, umschaltbar auf externe Antenne
Beschriftung in Französisch (GO und PO)
- Net weight (2.2 lb = 1 kg)
- 1.5 kg / 3 lb 4.9 oz (3.304 lb)
- Author
- Model page created by Alois Wolf. See "Data change" for further contributors.
- Other Models
-
Here you find 61 models, 41 with images and 12 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Visseaux / Télévisso; Lyon / Paris
