- Country
- France
- Manufacturer / Brand
- Visseaux / Télévisso; Lyon / Paris
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 351827
- Number of Transistors
- 12
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 3LR12: 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Scala - Visseaux / Télévisso; Lyon /
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 300 x 200 x 110 mm / 11.8 x 7.9 x 4.3 inch
- Notes
-
Alimentation par 2 piles plates 4,5 volts type 3LR12, cadran des stations en arc de cercle, bande FM de 86,5 à 108 MHz, haut-parleur elliptique Siare13x19 cms 12 Ohms, antenne télescopique orientable pour OC et FM.
3 boutons: volume, tonalité + stations, clavier 5 touches. Prises antenne auto-radio commutable + écouteur.
Équivalent au Sonolor Ambassadeur
- Author
- Model page created by Vincent Baccialone. See "Data change" for further contributors.
