• Country
• France

• Manufacturer / Brand
• Welpa, P. Weber & Cie, Weber Frères; Levallois-Perret, Paris

• Year
• 1954 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 196769

• Number of Tubes
• 6

• Valves / Tubes
• 6AJ8 6BA6 6AV6 6AQ5 EM34 6X4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19 cm = 7.5 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Inconnu - unknown 1 - Welpa, P. Weber & Cie, Weber

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 520 x 330 x 240 mm / 20.5 x 13 x 9.4 inch

• Notes
• Équipé antenne ferrite mobile avec un bouton à gauche de la radio.
  Écran est fabrication Aréna .

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Author
• Model page created by Bekir Yurdakul. See "Data change" for further contributors.

• Other Models

• Here you find 10 models, 9 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Welpa, P. Weber & Cie, Weber Frères; Levallois-Perret, Paris
