H-716T17 Ch= V-2208-1

Westinghouse El. & Mfg. Co. - see also Canadian W.

Datos

Foro

Imágenes

Colecciones

País
Estados Unidos

Fabricante / Marca
Westinghouse El. & Mfg. Co. - see also Canadian W.

Año
1952

Categoría
Televisión (TV) o monitor

Radiomuseum.org ID
163818

- alternative name: Westinghouse El. Int.

Imágenes
Esquemas

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222953) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222954) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222955) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222957) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222958) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222959) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222960) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222961) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222962) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222963) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222964) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222965) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222966) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222967) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222968) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222969) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1222970) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (3)

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 1219486) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (2)
Picture from Westinghouse datasheet

H-716T17 Ch= V-2208-1; Westinghouse El. & (ID = 680454) Televisión — Westinghouse El. & H-716T17 Ch= V-2208-1 (2)
Manufacturers Literature

Haga clic en la miniatura esquemática para solicitarlo como documento gratuito.

Especificaciones técnicas

Numero de valvulas
20

Válvulas
6BZ7 or 6BQ7 6J6 6CB6 6CB6 6CB6 12BY7 6AU6 6BN6 6BK5 12BH7 12AT7 6SN7GT 6AU6 6AL5 12AU7 6BQ6GT 6W4GT 1B3GT 5Y4G 17HP4

Principio principal
Superheterodino con paso previo de RF

Gama de ondas
VHF/UHF (see notes for details)

Tensión de funcionamiento
Red: Corriente alterna (CA, Inglés = AC) / 105-120 Volt

Altavoz
Altavoz dinámico (de imán permanente) / Ø 5.25 inch = 13.3 cm

Potencia de salida
1.8 W (unknown quality)

Material
Metálico

de Radiomuseum.org
Modelo: H-716T17 Ch= V-2208-1 - Westinghouse El. & Mfg. Co. -

Forma
Sobremesa alto de forma simple.

Anotaciones
The Westinghouse H-716T17 is a 17" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis V-2208-1 and picture tube 17HP4.

Procedencia de los datos
- - Manufacturers Literature

Documentación / Esquemas (1)
- - Manufacturers Literature (Westinghouse Datasheet RM3317)

Autor
Modelo creado por un miembro de A. Ver en "Modificar Ficha" los participantes posteriores.

Otros modelos
Donde encontrará 3151 modelos, 1750 con imágenes y 2665 con esquemas.
Ir al listado general de Westinghouse El. & Mfg. Co. - see also Canadian W.

Colecciones | Museos | Literatura

Forum
