CDX-900

Yamaha Co.; Hamamatsu

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Yamaha Co.; Hamamatsu

Year
1987

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
199873

- alternative name: Nippon Gakki

Schematics

CDX-900; Yamaha Co.; (ID = 1027386) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027387) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027388) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027390) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027392) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027393) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027394) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027395) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027396) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027397) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027398) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027399) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027400) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027401) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027402) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027403) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027404) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027405) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027406) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027407) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027408) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027409) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027410) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027411) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027412) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027413) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027414) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 1027415) R-Player — Yamaha Co.; CDX-900 (3)

CDX-900; Yamaha Co.; (ID = 2704432) R-Player — Yamaha Co.; CDX-900 (1)

CDX-900; Yamaha Co.; (ID = 2704431) R-Player — Yamaha Co.; CDX-900 (1)

CDX-900; Yamaha Co.; (ID = 2704440) R-Player — Yamaha Co.; CDX-900 (1)

CDX-900; Yamaha Co.; (ID = 1027385) R-Player — Yamaha Co.; CDX-900 (2)
Original Yamaha Prospect

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
37

Semiconductors

Main principle
Audio-Amplification

Wave bands
- without

Details
CD-Player, -Writer, MD, MOD (audio)

Power type and voltage
Alternating Current supply (AC) / 220-240 Volt

Loudspeaker
- For headphones or amp.

Material
Metal case

from Radiomuseum.org
Model: CDX-900 - Yamaha Co.; Hamamatsu

Shape
Book-shelf unit.

Dimensions (WHD)
435 x 107 x 347 mm / 17.1 x 4.2 x 13.7 inch

Notes
Compact Disc Player. Hi-Bit Digitalfilter mit Vierfach-Oversampling, DC-Verstärker mit aktivem Analogfilter 5. Ordnung, separate nebenschlussregulierte Stromversorgung, Twin High-Speed D/A Konverter.
24 Titel durch direkte Anwahl, beliebig programmierbare Wiedergabe, Delete Programm, Random Play, 8-stellige Multifunktions-Fluoreszenzanzeige, Kalender-Display, 4-fache Wiederholfunktion, Manual Space Insert, Index-Suchlauf, 3-facher Musik-Suchlauf, Kopfhörerausgang mit Pegelregler, vergoldete Anschlüsse, Fernsteuerung mit 42 Tasten, Integriert im RS-Fernsteuersystem.

13 ICs.

Net weight (2.2 lb = 1 kg)
6.5 kg / 14 lb 5.1 oz (14.317 lb)

Price in first year of sale
1,443.00 DM

Source of data
-- Original prospect or advert

Author
Model page created by a member from D. See "Data change" for further contributors.
