LW6
Zerdik; Wien
- Country
- Austria
- Manufacturer / Brand
- Zerdik; Wien
- Year
- 1932/1933
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 11012
Zerdik-Werbung im Jahre 1932
- Number of Tubes
- 4
- Main principle
- TRF with regeneration; 1 Special; 1 AF stage(s); something special ? Please give information (notes)
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 6 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: LW6 - Zerdik; Wien
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 415 x 335 x 465 mm / 16.3 x 13.2 x 18.3 inch
- Notes
- Tragbare Loftin-White-Universalanlage mit eingebautem Plattenspieler, speziell für Gaststätten. Wellenbereich 200...600 m. Eingebauter Ausgangstransformator für den wahlweisen Anschluß von dynamischen oder magnetischen Lautsprechern. Aufpreis für Geldeinwurfautomat ATS 100.-
- Net weight (2.2 lb = 1 kg)
- 20 kg / 44 lb 0.8 oz (44.053 lb)
- Price in first year of sale
- 980.00 ATS
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
