• Country
• Romania

• Manufacturer / Brand
• Electronica; București - Bucharest

• Year
• 1968 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 217934

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• ECC82 6BQ7A ECF80 EF80 PY82 6AL5 PCL82 EF184 PL83 PCF82 EY86 PY88

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 120; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1 W (unknown quality)

• from Radiomuseum.org
• Model: E 43 VS 43-643 - Electronica; București -

• Dimensions (WHD)
• 597 x 352 x 397 mm / 23.5 x 13.9 x 15.6 inch

• Notes
• Diodes: EFD106 WJ1
  IF picture: 38 MHz
  IF audio I: 31.5 MHz
  IF audio II: 6.5 MHz
  Aerial input: 75 Ohm
  Power consumption: 180 VA
  CRT Tube: AW 43-88 110 degree
  Horizontal lines resolution: 450
  Audio frequency response: 80-9000 Hz
  Picture size: 355x270 mm

• Net weight (2.2 lb = 1 kg)
• 28 kg / 61 lb 10.8 oz (61.674 lb)

• External source of data
• Scheme de Televizoare Magnetofoane, Picupuri Ed.2 1976

• Author
• Model page created by Adalbert Blenessy. See "Data change" for further contributors.
