• Country
• Romania

• Manufacturer / Brand
• Electronica; București - Bucharest

• Year
• 1960

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 307738

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 450 kHz

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 2x4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 10 cm = 3.9 inch

• Power out
• 0.25 W (10 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mioriţa 1 S-60T - Electronica; București -

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 317 x 213 x 168 mm / 12.5 x 8.4 x 6.6 inch

• Notes

• Table version of model Litoral.

• Net weight (2.2 lb = 1 kg)
• 3.6 kg / 7 lb 14.9 oz (7.93 lb)

• Mentioned in
• - - Manufacturers Literature (T. Chiric: Scheme de radioreceptoare; 1973, p. 121-3)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Literature/Schematics (2)
• -- Original-techn. papers.

• Author
• Model page created by Ion Mândreş. See "Data change" for further contributors.
