551 output tube EL41
Pathé Radio, Pathé Frères (Pathéphone); Paris
- Country
- France
- Manufacturer / Brand
- Pathé Radio, Pathé Frères (Pathéphone); Paris
- Year
- 1951/1952
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 180511
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: 551 [output tube EL41] - Pathé Radio, Pathé Frères Path
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 450 x 300 x 250 mm / 17.7 x 11.8 x 9.8 inch
- Notes
-
4 gammes d'ondes: GO 1000 à 2000 m, PO 165 à 575 m, OC 16 à 51 m, OC étalées sur 50 m. Prises antenne terre et pick-up. Lampe cadran : 220-230 V, 25 W, E14.
Ébénisterie noyer verni, façade en métal laqué bruin avec décoration or, ou en métal doré.
Équivalent au Marconi 51 (551).
- Mentioned in
- -- Original prospect or advert (Marconi Saison 1952)
- Author
- Model page created by Ottmar Lauth. See "Data change" for further contributors.
